Alitherm 700 Aliminium Windows


Alitherm Series of windows offer a range of high quality glazing solutions for side hung, top hung open out, top swing reversible and parallel opening casements, suitable for both the residential and commercial markets.

The series features products that achieve;

  • Window Energy Rating A
  • BRE Green Guide A
  • U Values up to 1.2 W/m2K depending on system and glass unit
  • Includes the Kitemarked systems Alitherm 600 and 800 PAS 24:2012 Security

This versatile range of profiles can provide many solutions such as traditional casement windows inspired by the elegance and styling of timber products, or automatic parallel opening commercial windows designed to provide a balance airflow in multi-storey commercial buildings.

All Alitherm profiles utilise Smart’s innovative polyamide thermal break technology which creates a barrier between the cold air outside and the warm air inside. The technology significantly reduces thermal transmittance and enhances the overall U Value of a product.

  • Description
  • Specifications
  • Performance
  • Dimensions

Alitherm 700 is an innovative solution for enhanced natural ventilation. The system allows for a balanced, effective airflow whilst maintaining security and safety. The system can also be either a side or top hung casement, or top swing reversible window.

Alitherm profiles utilise Smart’s innovative polyamide thermal break technology which creates a barrier between the cold air outside and the warm air inside. This technology significantly reduces thermal transmittance and enhances the overall U Value of a product and is designed to meet the exacting requirements of Document L 2010.

Alitherm products are available in a choice of standard or non-standard colours, including metallic, dual colour, Smart’s Sensations textured, and Alchemy anodised effect finishes.

  • Alitherm 700 is ideal for insertion into curtain wall facades in both low and high rise commercial buildings
  • The system is suitable for use as either replacement windows in existing buildings, or for installation into new builds
  • Alitherm 700 incorporates internally beaded vents suitable for either cockspur or shoot-bolt locking.
  • The system is also suitable for use with chain-operators, operated either individually or as part of an integrated automated solution for building climate control
  • Smoke ventilation available soon. Check with your supplier
  • British Standard Kitemarked system: KM 815580 PAS 24:2102, KM 81543 BS4873
  • Brand ...... Alitherm
  • Material ...... Aluminium Polyamide
  • Dual Colour ...... Yes
  • Thermally Broken ...... Yes
  • NBS Available ...... Yes
  • WER Rating ...... A
  • U Value ...... 1.6W/W/m²K (using correct glass unit)
  • Document L Compliant ...... Yes
  • Kitemark ...... Yes
  • BS 6375-1:2009 ...... Yes
  • BS 7950:1997 ...... Yes
  • BS 4873 ...... Yes
  • Side Hung Max Width (mm) ...... 838mm
  • Side Hung Max Height (mm) ...... 1729mm
  • Top Hung Max Width (mm) ...... 1729mm
  • Top Hung Max Height (mm) ...... 2000mm
  • Reversible Max Width (mm) ...... 1500mm
  • Reversible Max Height (mm) ...... 1558mm
  • Parallel Max Width (mm) ...... 2000mm
  • Parallel Max Height (mm) ...... 3000mm
  • Parallel Max Weight (kg) ...... 100kg - sashes above 100kg or 1500mm wide should be motorised operation only
  • Glazing (mm) ...... 28mm double or triple glazed units
  • Frame Depth (mm) ...... 70mm
