Visofold 6000 Patio Door


Visoglide Plus offers the same contemporary styling and robust performance associated with the system whilst delivering superior thermal performance.

Visoglide Plus offers the same contemporary styling and robust performance associated with the system whilst delivering superior thermal performance.

This adaptable system is suitable for use as either sliding commercial entrances where large opening apertures are required, or as dynamic residential sliding doors that maximise light and give stunning unimpeded views. Visoglide Plus profiles have been designed to improve both strength and weather resistance. All main sections feature an extended polyamide thermal break that allows Visoglide Plus to achieve a U Value of 1.6 W/m²K when installed with a suitable sealed unit.

  • Description
  • Specifications
  • Performance
  • Dimensions

Visoglide Plus doors are available in both single and dual colour in wide choice of standard and non-standard finishes including Smart’s unique Sensations range of textured colours. The system is also suitable for use with auto slide opening mechanisms (sold seperately).

  • Inline sliding or lift & slide options
  • Slim interlock option
  • Colour matched accessories now available speak with your supplier for details
  • British Standard Kitemarked system achieving: KM 530838 PAS 24:2012
  • Brand ...... Visofold
  • Material ...... Aluminium Polyamide
  • Dual Colour ...... Yes
  • Thermally Broken ...... Yes
  • NBS Available ...... Yes
  • U Value ...... 1.6 W/m²K based on using a sealed unit with 1.0 W/m²K centre pane
  • Document L Compliant ...... Yes
  • BS 6375-1:2009 ...... Yes
  • Slide Folding Door Max Width (mm) ...... 1000mm (per sash)
  • Slide Folding Door Max Height (mm) ...... 2500mm (per sash)
  • Slide Folding Door Max Weight (kg) ...... 250kg
  • Glazing (mm) ...... 38mm double or triple glazed units
  • Frame Depth (mm) ...... 100mm
  • Typical Sightlines (mm) ...... 117mm (OF) 83mm (Interlock)
